MP2410AGJ-Z: 2A, 1MHz, synchronous buck LED driver with analogue dimming only

Product Details:

Model: MP2410AGJ-Z

Package: TSOT23-6

Type: LED driver

Overview:

The MP2410AGJ-Z is a 24V monolithic synchronous buck white LED driver with integrated power MOSFET and rectifier. It delivers up to 2A of continuous output current with excellent load and line regulation. Peak current control mode provides fast transient response and facilitates loop stabilisation.

The MP2410AGJ-Z enables deep analogue dimming. Comprehensive protection features include cycle-by-cycle peak current limiting, output short-circuit protection (SCP), LED open-circuit protection, external NTC over-temperature protection, and over-temperature shutdown.

MP2410AGJ-Z Specifications:

Type: DC-DC Regulator

Topology: Buck

Internal Switch: Yes

Number of Outputs: 1

Voltage - Supply (Min): 4.2V

Voltage - Supply (Max): 24V

Current - Output/Channel: 2A

Frequency: 1MHz

Dimming: Analogue, PWM

Application: Backlighting

Operating Temperature: -40°C to 125°C (TJ)

Mounting Type: Surface Mount

Package/Case: SOT-23-6 Fine, TSOT-23-6

Supplier Device Package: TSOT-23-6

MP2410AGJ-Z Product Features:

Wide Input Voltage Range: 4.2V - 24V

Synchronous Buck Converter

Integrated 100mΩ Top Switch

Integrated 80mΩ synchronous rectifier

Peak current control mode

Up to 2A continuous output current

100mV feedback voltage

Efficiency up to 97%

1MHz fixed switching frequency

Analogue dimming capability

Cycle-by-cycle current limit protection

LED open-circuit protection

Output short-circuit protection (SCP)

NTC over-temperature protection

Over-temperature shutdown protection

Auto-restart function
