The TLD7002-16ES is a 16 channel device with integrated and protected output stages. It is designed to control LEDs with a current up to 76.5 mA as linear current sink (LCS). The power stages can be configured in parallel for higher load currents. Each individual power output stage is configured to a 6-bit current set value stored in the OTP. 16 independent and individual PWM configurations can be set. A high-speed lighting interface is used for device OTP programming, configuration, control and diagnostic feedback.

TLD7002-16ES Features

• 16 channel device with integrated and protected output stages, optimized to drive LEDs

• High regulated output current up to 76.5 mA per channel

• Parallel output operation for higher load currents

• 16 independent 6-bit configurable global output current configurations ranging from 5.625 mA to 76.5 mA

• 16 independent 14-bit PWM engines from 100 Hz up to 2 kHz

• Configurable thermal derating

• Configurable LED Open, Short and Single-LED-Short thresholds

• Digital feedback of external two voltage measurements (NTC/PTC)

• Integrated HSLI transceiver, CAN-FD physical-layer compatible up to 2 MBit/s

• Developed according to ISO26262 with process complying to ASIL-B

TLD7002-16ES Potential Applications

• Open-drain LED driver with high-speed lighting interface (HSLI - UARToverCAN)

• Automotive rear light functions such as tail, stop and sequential (dynamic) turn indicator

• Animated light functions like “welcome/goodbye” functions

• Interior lighting functions for ambient lighting (RGB color control), illumination and dash board lighting

• LED panels for industrial applications and instrumentation
