The MP2315GJ is a high-frequency synchronous rectification buck switch-mode converter with an integrated power MOSFET. It provides an exceptionally compact solution, delivering 3A continuous output current across a wide input range with outstanding load and line regulation.

The MP2315GJ operates in synchronous mode across the output current load range to achieve high efficiency. Its current-mode control provides fast transient response and facilitates easier loop stabilisation. Comprehensive protection features include overcurrent protection (OCP) and overtemperature shutdown.

The MP2315GJ minimises the use of standard external components and is housed in a space-saving 8-pin TSOT23 package.

MP2315GJ Product Features and Benefits

Wide operating input voltage range: 4.5V to 24V

3A load current

Integrated 90mΩ/40mΩ low on-resistance power MOSFETs

Low quiescent current

High-efficiency synchronous operation mode

500kHz fixed switching frequency

Synchronisation capability with external clock frequencies from 200kHz to 2MHz

Advanced Asynchronous Modulation (AAM) power-saving mode

Internal soft-start

Overcurrent protection (OCP) with hiccup protection

Over-temperature shutdown protection

Adjustable output voltage down to 0.8V

8-pin TSOT-23 package

MP2315GJ   Product Attributes

Product Type:    Switching Regulator

Mounting Style:    SMD/SMT

Package / Case:    TSOT-23-8

Topology:    Buck

Output Voltage:    800 mV to 22.8 V

Output Current:    125 mA

Number of Outputs:    1 Output

Input Voltage - Minimum:    4.5 V

Input Voltage - Maximum:    24 V

Switching Frequency:    500 kHz

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Series:    MP2315
