The NCV5661MN12T2G is a high performance low-drain (LDO) linear regulator for high power applications requiring up to 1.0 A. It is available in fixed and adjustable output versions. Available in fixed and adjustable output versions, the NCV5661MN12T2G offers output voltages as low as 0.9 V, ultra-fast response times to transient loads, and additional features such as enable and error flags (for the fixed output version) to enhance the usability of this device. The thermally robust, 5-pin DFN 3.0 x 3.3 mm, combined with a low ground current regardless of load structure, provides an excellent high current LDO solution.

NCV5661MN12T2G Applications

Server

Network Equipment

Automotive

NCV5661MN12T2G Features

Ultra-fast transient response (settling time: 1-3 µs)

Low noise (no bypass capacitors) (26 µVrms)

Low load-independent ground current (3.0 mA max)

Fixed/adjustable output versions

Enable Function

Error flag (fixed output version)

Current limit protection

Thermal protection

0.9 V reference voltage for ultra-low output operation

Power supply rejection ratio > 65 dB

NCV5661MN12T2G Product Attributes

Product Category: Low Dropout Regulators

Mounting Style: SMD/SMT

Package / Case: DFN-6

Output Voltage: 1.2 V

Output Current: 1 A

Number of Outputs: 1 Output

Polarity: Positive

Quiescent Current: 3 mA

Input Voltage - Min: 2 V

Input Voltage - Max: 9 V

Output Type: Fixed

Minimum operating temperature: - 40 C

Maximum operating temperature: + 150 C

Setback Voltage: 1 V

Qualification: AEC-Q100

Return Voltage - Max: 1.3 V at 1 A

Height: 0.85 mm

Length: 3 mm

Line regulation: 0.03 %

Load regulation: 0.2 %
