The LT3060ETS8-5 is a low-power, low-dropout (LDO) linear regulator capable of operating within an input voltage range of 1.6V to 45V. The device provides an output current of 100mA and a typical dropout voltage of 300mV. A single external capacitor enables programmable low-noise reference performance and output soft-start functionality. The LT3060ETS8-5 has a quiescent current of only 40μA and achieves fast transient response using a minimum 2.2μF output capacitor. In shutdown mode, the quiescent current is less than 1μA, and the reference soft-start capacitor is reset.

The LT3060ETS8-5 regulator optimises stability and transient response using low ESR ceramic output capacitors. Unlike other regulators, this regulator does not require additional ESR.

Features (LT3060ETS8-5)

Input voltage range: 1.6V to 45V

Output current: 100mA

Quiescent current: 40μA

Dropout voltage: 300mV

Low noise: 30μVRMS (10Hz to 100kHz)

Adjustable output: VREF = 600mV

Fixed output voltages: 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V, 15V

Output tolerance: ±2% (across the entire line, load, and temperature range)

Single-capacitor soft-start reference voltage source and low output noise

Shutdown current: < 1μA

Battery reverse polarity protection

Current limit foldback protection

Thermal limit protection

8-pin ThinSOT™ package

Certified for automotive applications per AEC-Q100

Applications (LT3060ETS8-5)

Battery-powered systems

Automotive power supplies

Industrial power supplies

Aeronautical electronics power supplies

Portable instruments
