Trade Name:Low-dropout Voltage Regulator
Brand:ON
Particular Year:23+
Package:DPAK-5
Delivery Date:New and Original
Stock: 15000pcs
The NCV4276BDT33RKG is a series of integrated low-dropout regulators designed specifically for harsh automotive environments, featuring a 400 mA output current. This series offers a wide operating temperature range and input voltage range. The device is available in both fixed voltage and adjustable voltage versions, with an output voltage accuracy of 2%. It features high peak input voltage withstand capability and reverse input voltage protection. Additionally, it provides overcurrent protection, over-temperature protection, and suppression functionality for output voltage state control. The NCV4276BDT33RKG is available in a DPAK surface-mount package. The output remains stable across a wide range of output capacitance and ESR values. The NCV4276BDT33RKG exhibits improved startup behaviour during input voltage transients.
NCV4276BDT33RKG Features
Automotive-grade reliability: Complies with AEC-Q100 Grade 1 standards, operating temperature range -40°C to 150°C, suitable for harsh environments.
Low static current (Iq): Only 200µA, optimising energy efficiency for battery-powered devices.
High PSRR (Power Supply Rejection Ratio): 70dB @ 100Hz, effectively suppressing input power supply noise and enhancing system stability.
Protection features: Over-temperature protection (OTP), reverse polarity protection, and short-circuit protection, enhancing system safety.
Wide input voltage range: 4.5V to 40V (some specifications indicate 45V), compatible with 12V/24V automotive power systems.
NCV4276BDT33RKG Parameters
Output voltage: 3.3V (fixed)
Output current: 400mA (maximum)
Input voltage range: 4.5V to 40V (some specifications indicate 45V)
Dropout voltage (Vdrop): 250mV (typical)
Quiescent current (Iq): 200µA
PSRR: 70dB @ 100Hz
Package: DPAK-5 (TO-252-5)
Operating temperature: -40°C to 150°C
Model
Brand
Package
Quantity
Describe
ON
SOIC-8
2500
Low Dropout Regulator 100 mA, 40 V, 120 µA Input Current, with Reset and Output Detection Functions
TI
VQFN-20
15800
3A, low input voltage (1.1V), low noise, high precision, ultra-low dropout voltage regulator
ON
SO-8
5000
150 mA LDO Linear Regulator with Reset, Delay, Adjustable Reset, and Early Warning
INFINEON
PG-SSOP-14
2000
Monolithic Integrated Low Dropout Regulator in PG-SSOP-14 EP Exposed Pad Package
