The NCP59748MN1ADJTBG is an ultra-low dropout regulator capable of delivering over 1.5 A of output current at full load, with a typical dropout voltage of 60 mV. The device is compatible with ceramic capacitors and other types of output capacitors (≥ 2.2 µF). This product includes a version with an adjustable output voltage, which can be as low as 0.8 V. Internal protection features include built-in thermal shutdown and output current limit protection. User-programmable soft-start and power-good pins are available in the DFN version. NCP59748MN1ADJTBG is available in a DFN10 3×3 package.

Features of NCP59748MN1ADJTBG

• Output current exceeds 1.5 A

• Input voltage range: 0.8 V to 5.5 V

• Bias voltage range: 2.7 V to 5.5 V

• Output voltage range: 0.8 V to 3.6 V

• Dropout voltage: 60 mV at 1.5 A

• Programmable soft-start

• Open-drain power good output

• Fast transient response

• Suitable for any type of output capacitor (≥2.2 F)

• Current limit and thermal shutdown protection

• These are lead-free devices

NCP59748MN1ADJTBG Product Attributes

Product Type: Low Dropout Regulator

Mounting Style: SMD/SMT

Package/Case: DFN-10

Output Voltage:    800 mV to 3.6 V

Output Current:    1.5 A

Number of Outputs:    1 Output

Polarity:    Positive

Input Voltage - Minimum:    800 mV

Input Voltage - Maximum:    5.5 V

PSRR/Ripple Rejection — Typical:    60 dB

Output Type:    Adjustable

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Reverse Voltage:    60 mV

Series:    NCP59748

Applications of NCP59748MN1ADJTBG

• Point-load regulation for consumer and industrial equipment

• Power supply for FPGAs, DSPs, and logic circuits

• Post-regulator for switch-mode power supplies
