The ADAU1361BCPZ is a low-power stereo audio codec supporting stereo 48 kHz recording and playback, operating from a 1.8 V analogue supply with a power consumption of 10 mW. The stereo audio ADC and DAC support sampling rates ranging from 8 kHz to 96 kHz and incorporate digital volume control. This device is ideally suited for battery-powered audio and telephony applications.

The recording path incorporates an integrated microphone bias circuit and six input paths. Multiple inputs can be mixed and multiplexed prior to the ADC. Alternatively, analogue inputs may bypass the mixing section and be routed directly to the output analogue mixer. The device also supports stereo digital microphone inputs.

The ADAU1361BCPZ incorporates five high-power output drivers (two differential, three single-ended) supporting Surround Sound Headphones, earphones, or other output transducers. The device also supports AC-coupled or capacitorless configurations. All seven output pins feature independent precision level control. The output mixer stage enables flexible audio routing.

The serial control bus supports both I²C and SPI protocols. The serial audio bus is programmable for I²S, left/right-aligned, or TDM modes. A programmable PLL enables flexible generation of all standard integer clock frequencies and fractional master clock frequencies from 8 MHz to 27 MHz.

Features (ADAU1361BCPZ)

24-bit stereo audio analogue-to-digital converter and digital-to-analogue converter: >98 dB signal-to-noise ratio

Sampling rate range: 8 kHz to 96 kHz

Low power consumption: 7 mW recording, 7 mW playback at 48 kHz with 1.8 V supply

6 analogue input pins, configurable as single-ended or differential inputs

Flexible analogue input/output mixer<BR />Stereo digital microphone input<BR />Analogue outputs: 2 differential stereo, 2 single-ended stereo, 1 mono headphone output driver<BR />PLL supports 8 MHz to 27 MHz input clocks<BR />Analogue automatic level control (ALC)<BR />Microphone bias reference voltage

I²C and SPI control interfaces

Digital audio serial data I/O: stereo and time-division multiplexing (TDM) modes

Software-controllable click-free mute

Software shutdown capability

32-pin 5mm × 5mm LFCSP package

Operating temperature range: -40°C to +85°C

Applications (ADAU1361BCPZ)

Smartphones and multimedia phones

Digital cameras and camcorders

Portable media players and portable audio players

Telephone accessories
