The ADM706RARZ is a microprocessor monitoring circuit manufactured by Analog Devices designed for monitoring 3V or 3.3V power supplies. It provides a power monitoring circuit that generates a reset output under power-on, power-off, and undervoltage conditions. Additionally, the chip features an independent watchdog monitoring circuit, which activates if the watchdog input does not toggle within 1.6 seconds.

ADM706RARZ Features

Precision power supply voltage monitor: Provides a reset threshold of 2.63V.

Low static current: Static current is only 100µA.

Configurable reset pulse width: Reset pulse width is 200ms.

Debounced manual reset input: Provides an effective low-debounce MR input.

Independent watchdog timer: Features a 1.6-second timeout function.

Voltage monitor: Used for power failure alarms, low battery detection, or monitoring additional power sources.

Ensures RESET is effective when VCC = 1V.

RoHS compliant: Meets environmental protection requirements.

ADM706RARZ Product Attributes

Manufacturer: Analog Devices Inc.

Product Type: Monitoring Circuit

Mounting Style: SMD/SMT

Package/Case: SOIC-8

Threshold Voltage: 2.63 V

Number of Monitored Inputs: 1 Input

Output Type: Active Low, Push-Pull

Manual Reset:    Manual Reset

Watchdog Timer:    Watchdog

Battery Backup Switch:    No Backup

Reset Delay Time:    200 ms

Supply Voltage - Maximum:    5.5 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

Series:    ADM706

Chip Enable Signal:    No Chip Enable

Height:    1.5 mm (Max)

Length:    5 mm (Max)

Operating Supply Current:    250 μA

Overvoltage Threshold:    2.7 V

Pd-Power Dissipation:    470 mW

ADM706RARZ Product Applications

Microprocessor Systems

Computers

Controllers

Smart Instruments

Critical Microprocessor Power Monitoring
