Commodity Model:STPMIC1DPQR

Trade Name:STPMIC1DPQR

Data Manual:STPMIC1DPQR.pdf

Brand:ST

Particular Year:23+

Package:WFQFN44

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ST
Model
STPMIC1DPQR
Package
WFQFN44
Describe
Highly integrated power management IC for micro processor units

Product Description

The STPMIC1DPQR power management IC is a wide fully integrated PMIC designed for use in highly integrated application processor based designs where low power consumption and high efficiency are required.The STPMIC1 PMIC integrates advanced low power features and is controlled by the host processor via I2C and IO interfaces. The PMCI integrates four synchronous buck converters which are optimised for ultra-high efficiency. The device also contains low dropout voltage (LDO) regulators to power the application processor as well as system peripherals such as DDR memory, flash memory and other system devices.

The STPMIC1DPQR's boost converter can drive up to three USB ports (two 500mA host USB and one 100mA USB OTG.) The STPMIC1's advanced bypass architecture smoothly regulates the VBUS of the USB ports on batteries as well as consumer 5V AC-DC adapters.

The STPMIC1DPQR power management IC is available in a WFQFN-44L package and has an ambient operating temperature range of -40°C to +105°C.


Features

Input voltage range: 2.8V to 5.5V

4 adjustable general purpose LDOs

1 LDO for DDR3 termination (fill current - pull current), bypass mode for low power DDR or as a general purpose LDO

1 LDO for USB PHY power supply with automatic power detection

1 reference voltage LDO for DDR memory

4 adjustable adaptive constant on-time (COT) step-down SMPS converters

5.2V/1.1A step-up SMPS with bypass mode for 5V input or battery input

1 x 500mA power switch, USB OTG compliant

1 x 500mA/1000mA universal power switch

User programmable non-volatile memory (NVM), scalable to support a wide range of applications

I2C and digital I/O control interface

Ambient operating temperature range: -40°C to +105°C

Package type: WFQFN-44L

Package size: 5.0mm x 6.0mm x 0.8mm


Applications

Power management unit companion chip for STM32MP1 microcontrollers

Power management for embedded microprocessors

Wearable devices and IoT

Portable devices

Human Machine Interface (HMI)

Smart Home
