STM32H750VBT6TR is based on the high-performance Arm® Cortex®-M7 32-bit RISC core operating at up to 480 MHz. The Cortex® -M7 core features a floating point unit (FPU) which supports Arm® double-precision (IEEE 754 compliant) and single-precision data-processing instructions and data types. STM32H750VBT6TR support a full set of DSP instructions and a memory protection unit (MPU) to enhance application security.

STM32H750VBT6TR incorporate high-speed embedded memories with a flash memory of 128 Kbytes, up to 1 Mbyte of RAM (including 192 Kbytes of TCM RAM, up to 864 Kbytes of user SRAM and 4 Kbytes of backup SRAM), as well as an extensive range of enhanced I/Os and peripherals connected to APB buses, AHB buses, 2x32-bit multi-AHB bus matrix and a multi layer AXI interconnect supporting internal and external memory access.

Specification Of STM32H750VBT6TR

Series:STM32H7

Core Processor:ARM® Cortex®-M7

Core Size:32-Bit

Speed:480MHz

Number of I/O:82

Program Memory Size:128KB (128K x 8)

Program Memory Type:FLASH

RAM Size:1M x 8

Voltage - Supply (Vcc/Vdd):1.62V ~ 3.6V

Data Converters:A/D 16x16b; D/A 2x12b

Oscillator Type:Internal

Operating Temperature:-40°C ~ 85°C (TA)

Features Of STM32H750VBT6TR

Core

- 32-bit Arm® Cortex®-M7 core with doubleprecision FPU and L1 cache: 16 Kbytes of data and 16 Kbytes of instruction cache; frequency up to 480 MHz, MPU, 1027 DMIPS/ 2.14 DMIPS/MHz (Dhrystone 2.1), and DSP instructions

Memories

- 128 Kbytes of flash memory

- 1 Mbyte of RAM: 192 Kbytes of TCM RAM (inc. 64 Kbytes of ITCM RAM + 128 Kbytes of DTCM RAM for time critical routines), 864 Kbytes of user SRAM, and 4 Kbytes of SRAM in Backup domain

- Dual mode Quad-SPI memory interface running up to 133 MHz

- Flexible external memory controller with up to 32-bit data bus:

– SRAM, PSRAM, NOR flash memory clocked up to 133 MHz in synchronous mode

– SDRAM/LPSDR SDRAM

– 8/16-bit NAND flash memories

- CRC calculation unit

General-purpose input/outputs

- Up to 168 I/O ports with interrupt capability

11 analog peripherals

3× ADCs with 16-bit max. resolution (up to 36 channels, up to 3.6 MSPS)

1× temperature sensor

2× 12-bit D/A converters (1 MHz)

2× ultra-low-power comparators

2× operational amplifiers (7.3 MHz bandwidth)

1× digital filters for sigma delta modulator (DFSDM) with 8 channels/4 filters

Applications Of STM32H750VBT6TR

Industrial

- Home, building, and city automation

Personal electronics

- Home entertainment
