The NCV887001D1R2G is an adjustable output asynchronous boost controller designed to drive an external N-channel MOSFET. The device employs peak current mode control and incorporates slope compensation functionality. The IC incorporates an internal regulator to provide charging for the gate driver. Protection features include internally set soft-start, under-voltage lockout, periodic current limiting, short-circuit protection, and thermal shutdown. Additional features include a low static current sleep mode and external synchronous switching frequency.

NCV887001D1R2G Features

Peak current mode control with internal slope compensation

1.2 V ±2% reference voltage

Fixed-frequency operation

Wide input voltage range: 3.2 V to 40 Vdc, 45 V load dump

Input under-voltage lockout (UVLO)

Internal soft-start

Low static current in sleep mode

Periodic current limit protection

Intermittent mode overcurrent protection (OCP)

Intermittent mode short-circuit protection (SCP)

Thermal shutdown (TSD)

The NCV prefix is suitable for automotive and other applications requiring unique field and control change requirements; compliant with AEC-Q100 standards and supports PPAP

This device is a lead-free product

NCV887001D1R2G Product Attributes

Product Type: Switch Controller

Topology: Boost

Number of Outputs:    1 Output

Switching Frequency:    100 kHz

Duty Cycle - Maximum:    93 %

Output Voltage:    2.5 V

Output Current:    100 uA

Minimum Operating Temperature:    - 40 °C

Maximum Operating Temperature:    + 150 °C

Mounting Style:    SMD/SMT

Package/Case: SOIC-8

Qualification:    AEC-Q100

Insulation:    Non-Isolated

Operating Power Supply Current:    3 mA

Operating Power Supply Voltage:    3.2 V to 40 V

NCV887001D1R2G Applications

Start-Stop Systems

SEPIC (Non-Inverting Buck-Boost)

Direct Fuel Injection
