Trade Name:Switching Controllers
Brand:TI
Particular Year:22+
Package:MSOP-10
Delivery Date:New and Original
Stock: 2000pcs
LM5022MM device is a high-voltage, low-side, N-channel MOSFET controller ideal for use in boost and SEPIC regulators. It contains all of the features required to implement single-ended primary topologies. Output voltage regulation is based on current-mode control, which eases the design of loop compensation while providing inherent input voltage feedforward. The LM5022MM includes a start-up regulator that operates over a wide input range of 6 V to 60 V. The PWM controller is designed for high-speed capability including an oscillator frequency range up to 2.2 MHz and total propagation delays less than 100 ns. Additional features include an error amplifier, precision reference, line undervoltage lockout, cycle-by-cycle current limit, slope compensation, soft start, external synchronization capability, and thermal shutdown. The LM5022MM is available in the 10-pin VSSOP package.
Specification Of LM5022MM
Topology:Boost, Flyback, SEPIC
Number of Outputs:1 Output
Switching Frequency:200 kHz to 2.2 MHz
Duty Cycle - Max:90 %
Output Voltage:1.25 V to 300 V
Output Current:10 A
Minimum Operating Temperature:- 40 C
Maximum Operating Temperature:+ 125 C
Operating Supply Current:3.5 mA
Unit Weight:633 mg
Features Of LM5022MM
Internal 60-V start-up regulator
1-A Peak MOSFET gate driver
VIN Range: 6 V to 60 V (operates down to 3 V after start-up)
Duty cycle limit of 90%
Programmable UVLO with hysteresis
Cycle-by-cycle current limit
External synchronizable (AC-coupled)
Single resistor oscillator frequency set
Slope compensation
Adjustable soft start
10-Pin VSSOP package
Applications Of LM5022MM
Boost converters
SEPIC converters
Model
Brand
Package
Quantity
Describe
ADI
MSOP-10
2500
Switching Controller High Input Voltage, Current Mode Boost, Flyback and SEPIC Controllers
TI
VQFN-40
5000
Dual output, two-phase, stackable PMBus synchronous buck controller without driver
TI
VQFN-24
6000
Dual-channel synchronous buck controller with 100mA LDO and Out-of-Audio™, 4.5V to 28V
ON
SOIC-16
5000
Current Mode Resonant Controller (Integrated High Voltage Driver, Enhanced Light Load)
ADI
PQFN-28
3000
140V, low IQ, synchronous step-down type controller with programmable 5V to 10V gate drive
