The ISL95870BIRZ is a single-phase synchronous buck PWM controller in a QFN-EP-20 package, designed for applications such as GPU core power supplies, mobile PC motherboards, and embedded systems. The chip is based on Robust Ripple Regulator™ (R3) technology, offering high-precision voltage regulation, excellent transient response, and low-noise performance, making it ideal for efficient DC-DC conversion requirements.

ISL95870BIRZ Key Features

Wide input voltage range: 3.3V to 25V, suitable for battery-powered or AC adapter systems

Adjustable output voltage: 0.5V to 5V, meeting GPU core power supply requirements

High switching frequency: Supports 300kHz to 1MHz (programmable), optimising EMI performance

Remote voltage sensing: Enhances point-of-load (PoL) regulation accuracy

Automatic diode emulation mode: Improves light load efficiency

Power-Good monitoring: Provides soft-start and fault detection functionality

Wide temperature operating range: -40°C to +100°C, suitable for harsh environments

ISL95870BIRZ Product Attributes

Product Type: Switching Controller

Topology: Buck

Number of Outputs: 1 Output

Switching Frequency: 300 kHz to 1 MHz

Output Voltage: 500 mV to 5 V

Output Current: 30 A

Minimum Operating Temperature: -40°C

Maximum Operating Temperature:    +100°C

Mounting Style:    SMD/SMT

Package/Enclosure:    QFN-EP-20

ISL95870BIRZ Typical Applications

Laptop GPU Core Power Supply

Mobile PC Motherboard (ICH/GMCH Power Supply)

Embedded System DC-DC Conversion

Industrial Control Power Management
