The NCP13992ABDR2G is a high performance current mode controller for half-bridge resonant converters. This controller implements a 600V gate driver, simplifying the layout and reducing the number of external components required. A built-in undervoltage input function simplifies the implementation of the controller in all applications. In applications requiring a PFC preamp, the NCP13992 has a dedicated output to drive the PFC controller. This feature combined with dedicated Skip mode technology further improves light load energy efficiency throughout the application.The NCP13992 provides a suite of protection features for safe operation in any application. These include: overload protection, overcurrent protection against hard switching cycles, undervoltage detection, open optocoupler detection, automatic dead time regulation, overvoltage (OVP) and over temperature (OTP) protection.

NCP13992ABDR2G Product Attributes

Product Category: Switch Controller

Topology: Half Bridge

Switching Frequency: 20 kHz to 750 kHz

Output Voltage: 8.9 V

Output current: 1.65 mA

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C

Mounting Style: SMD/SMT

Package / Case: SOIC-16

Insulation: Non-Isolated

Humidity Sensitivity: Yes

Operating supply current: 5.4 mA

Product: AC/DC Converters

Product Type: Switching Controllers

Series: NCP13992

NCP13992ABDR2G Product Applications

Half Bridge Resonant Converters

Offline Power Supplies
