The STGSB200M65DF2AG is an IGBT developed using an advanced proprietary trench gate field cut-off structure.The device is part of the M-Series IGBTs. This device is part of the M-Series of IGBTs and offers the best balance between inverter system performance and efficiency. In addition, the positive VCE(sat) temperature coefficient and tight parameter distribution allow for safer parallel operation and safer operation. Thanks to the DBC footprint, the ACEPACK SMIT surface mount power module power packages have low thermal resistance and electrically isolated top thermal pads.

Product Attributes

IGBT Type: Trench Field Cutoff

Voltage - Collector Breakdown (Max): 650 V

Current - Collector (Ic) (max): 216 A

Current - Collector pulse (Icm): 700 A

Vce(on) at varying Vge, Ic (max): 2.05V @ 15V, 200A

Power - Max: 714 W

Switching Energy: 3.82mJ (on), 6.97mJ (off)

Input Type: Standard

Gate Charge: 554 nC

Td (on/off) value at 25°C: 122ns/250ns

Test Conditions: 400V, 200A, 4.7 Ohm, 15V

Reverse Recovery Time (trr): 174.5 ns

Operating Temperature: -55°C ~ 175°C (TJ)

Mounting Type: Surface Mount

Package/Housing: 9-PowerSMD

Supplier Device Package: 9-ACEPACK SMIT

Applications

• Traction Inverters
