LD39150PT is a fast, ultra-low dropout linear regulator operating within an input voltage range of 2.5 V to 6 V.

LD39150PT features low dropout voltage, low noise, and ultra-low quiescent current characteristics, making it ideal for low-voltage microprocessor and memory applications. The device is manufactured using BiCMOS technology, enabling low quiescent current operation independent of output load current.

LD39150PT Features

1.5 A guaranteed output current

Ultra-low dropout voltage (typical value of 200 mV at 1.5 A load, typical value of 40 mV at 300 mA load)

Extremely low quiescent current (typical value of 1 mA at 1.5 A load, maximum value of 1 µA at 25 °C in shutdown mode)

Logic-controlled electronic shutdown

Current and thermal internal limits

Output voltage tolerance of 1.5% at 25 °C

Fixed and adjustable output voltages: 1.8 V, 2.5 V, 3.3 V, ADJ

Temperature range: -40 to 125 °C

Fast dynamic response to line and load changes, stable with ceramic capacitors

LD39150PT Product Attributes

Product Type: Low Dropout Regulator

Mounting Style: SMD/SMT

Package/Case: TO-252-5

Output Voltage:    1.22 V to 5 V

Output Current:    1.5 A

Number of Outputs:    1 Output

Polarity:    Positive

Quiescent Current:    2.5 mA

Input Voltage - Minimum:    2.5 V

Input Voltage - Maximum:    6 V

Output Type:    Adjustable

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Regression Voltage:    40 mV

Series:    LD39150

Sag Voltage - Maximum:    80 mV at 300 mA

Height:    2.4 mm (Max)

Ib - Input Bias Current:    1 mA

Length:    6.6 mm (Max)

Line Regulation:    0.04 %

Load Regulation:    0.06 %/A

Reference Voltage:    1.22 V

LD39150PT Applications

Microprocessor Power Supply

DSP Power Supply

Final Stage Regulator for Switching Power Supplies

High-Efficiency Linear Regulator
