The STM32F303VET6 is a high-performance, low-power 32-bit microcontroller (MCU) based on the ARM Cortex-M4 core, operating at a clock speed of 72MHz. It features 512KB of Flash memory and 80KB of SRAM, making it ideal for applications in industrial automation, consumer electronics, medical devices, automotive electronics, and other fields. The chip is packaged in a 100-LQFP (14×14mm) package and supports a floating-point unit (FPU) and DSP instruction set, meeting complex computational requirements.

STM32F303VET6 Product Attributes

Product Type:    ARM Microcontroller - MCU

Series:    STM32F3

Mounting Style:    SMD/SMT

Package/Case:    LQFP-100

Core:    ARM Cortex-M4

Program Memory Size:    512 kB

Data Bus Width:    32-bit

ADC Resolution:    4 x 6-bit/8-bit/10-bit/12-bit

Maximum Clock Frequency:    72 MHz

Number of Input/Output Pins:    82 I/O

Data RAM Size:    64 kB

Supply Voltage - Minimum:    2 V

Supply Voltage - Maximum:    3.6 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +85°C

DAC resolution:    2 x 12-bit

Data RAM type:    SRAM

Interface type:    CAN, I2C, I2S, SPI, UART, USART, USB

Humidity sensitivity:    Yes

ADC channel count:    39 channels

Timer/counter count:    15 timers

Processor series:    STM32F3
