The IRS2186STRPBF is an EiceDRIVER™ 600 V high-side and low-side gate driver IC with typical 4 A source and 4 A sink currents in an 8-lead SOIC package for IGBTs and MOSFETs.

IRS2186STRPBF Features

Floating-channel design for self-starting operation

Operates up to +600 V

Withstands negative transient voltages, dV/dt unaffected

Gate drive supply range of 10 V to 20 V

Dual channel undervoltage lockout

Compatible with 3.3 V and 5 V input logic

Dual-channel propagation delay matching

Logic and supply ground +/- 5 V offset

Lower di/dt gate driver for better noise immunity

Output source/drain current capability 4 A/4 A

IRS2186STRPBF Product Attributes

Product Category: Gate Drivers

Product: IGBT, MOSFET Gate Drivers

Type: High-Side, Low-Side

Mounting Style: SMD/SMT

Package / Case: SOIC-8

Number of Exciters: 2 Driver

Number of Outputs: 2 Outputs

Output Current: 4 A

Supply Voltage - Min: 10 V

Supply Voltage - Max: 20 V

Rise time: 38 ns

Fall time: 30 ns

Minimum operating temperature: - 40 C

Maximum operating temperature: + 125 C

IRS2186STRPBF Applications

Wireless hoovers

Household appliances

Industrial automation

Light Electric Vehicles (LEV)

Power transmission and distribution
