For picture reference, please see the specifications
< >

Commodity Model:SAK-TC1791F-512F240EP AB

Trade Name:32-bit Microcontroller

Data Manual:SAK-TC1791F-512F240EP AB.pdf

Brand:INFINEON

Particular Year:23+

Package:BGA

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
INFINEON
Model
SAK-TC1791F-512F240EP AB
Package
BGA
Describe
TriCore™ TC17xx Microcontroller IC 32-bit Single Core 240MHz 4MB (4M x 8) Flash Memory PG-LFBGA-292-6

Product Description

The TC1791 is a high performance microcontroller with a TriCore CPU, program and data memory, bus, bus arbitration, interrupt controller, peripheral control processor and DMA controller and several on-chip peripherals.The TC1791 is designed to meet the needs of the most demanding embedded control system applications where price/performance, real-time responsiveness, computational power, data competing issues such as price/performance, real-time responsiveness, computational power, data bandwidth and power consumption are key design elements.

The TC1791 provides several general purpose on-chip peripheral units such as serial controllers, timer units and analogue-to-digital converters. Within the TC1791, all of these peripheral units are connected to the TriCore CPU/system via the Flexible Peripheral Interconnect (FPI) bus and the Crossbar Interconnect (SRI). several I/O lines on the TC1791 ports are reserved for these peripheral units to communicate with the external world.


Product attributes

Series: TC17xx

Packaging: Tape and Reel (TR)

Core Processor: TriCore™

Core specification: 32-bit single core

Speed: 240MHz

Connectivity: ASC, CANbus, FlexRay, MLI, MSC, SSC

Peripherals: DMA, POR, WDT

I/O count: 128

Program memory capacity: 4MB (4M x 8)

Program memory type: Flash

EEPROM size: 192K x 8

RAM size: 288K x 8

Voltage - Supply (Vcc/Vdd): 1.17V ~ 3.63V

Data converter: A/D 8x10b, 44x12b

Oscillator Type: External

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package / Case: 292-LFBGA

Supplier Device Package: PG-LFBGA-292-6

Basic Part Number: TC1791
