For picture reference, please see the specifications
< >

Commodity Model:TLE7259-3GE

Trade Name:Automotive LIN Transceiver

Brand:INFINEON

Particular Year:23+

Package:PG-DSO-8

Delivery Date:New and Original

Stock: 25000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
INFINEON
Model
TLE7259-3GE
Package
PG-DSO-8
Describe
High-performance automotive-grade LIN transceiver

Product Description

The TLE7259-3GE is a high-performance automotive-grade LIN transceiver. It is specifically designed for in-vehicle networks and supports data transfer rates from 2.4 kbps to 20 kbps, meeting the reliability and low-power requirements of modern automotive electronic systems.


TLE7259-3GE Key Features

Single-wire transceiver: Pin-compatible with the previous-generation TLE7259-2GE.

Data rate: Up to 20 kBaud.

LIN compliant: Supports LIN 1.3, 2.0, 2.1, and 2.2 standards.

Low power consumption: Typical static current in sleep mode is less than 8 µA.

High ESD robustness: ±15 kV, compliant with the IEC 61000-4-2 standard.

Optimised electromagnetic performance: Low electromagnetic emission (EME) and high electromagnetic immunity (EMI).

Wake-up functionality: Supports wake-up source detection.

Digital I/O level compatibility: Suitable for 3.3V and 5V microcontrollers.

Suitable for multiple power networks: Suitable for 12V and 24V automotive networks.

Protection features: Includes over-temperature protection, under-voltage detection, and bus short-circuit protection.

Environmental compliance: Complies with RoHS standards.


TLE7259-3GE Product Attributes

Manufacturer:    Infineon

Product Type:    LIN Transceiver

Supply Voltage - Maximum:    40 V

Supply Voltage - Minimum:    5 V

Operating Supply Current:    2.2 A

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +150°C

Mounting Style:    SMD/SMT

Package/Case:    DSO-8

Qualification:    AEC-Q100

Data Rate:    20 kb/s

Humidity Sensitivity:    Yes

Number of Channels:    1 Channel

Number of Drivers:    1 Driver

Number of Receivers:    1 Receiver

Operating Power Supply Voltage:    5 V to 40 V


Application Scenarios

The TLE7259-3GE is widely used in the following fields:

Automotive Electronics: Body control modules, gateway modules, switch panels, windscreen wiper and window lift modules, door and seat control modules, engine management units, etc.

Industrial Automation: Suitable for industrial networks requiring low power consumption and high reliability.
