Commodity Model:TPS92664QPHPRQ1

Trade Name:TPS92664QPHPRQ1

Data Manual:TPS92664QPHPRQ1.pdf

Brand:TI

Particular Year:23+

Package:HTQFP-48

Delivery Date:New original

Stock: 6000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
TI
Model
TPS92664QPHPRQ1
Package
HTQFP-48
Describe
16-CHANNEL LOW NOISE LED MATRIX

Product Description

The TPS92664QPHPRQ1 16-channel LED Matrix Manager enables full dynamic adaptive lighting solutions by providing separate pixel-level LED controls. The device comprises a three-series integrated switch of four substrings for bypass connection of independent leds. The device can accept a single or multiple current sources through a separate substring.

TPS92664-Q1 has an internal oscillator. Internal oscillators can be shared with other system components via internal low noise LVDS transmitter and receiver modules. The multipoint Branch Universal Asynchronous Transceiver (UART) serial interface is compatible with TPS92665, TPS92667, TPS92662x, and TPS92663x devices. Internal EEPROM can store system default and calibration as well as lighting module data. An onboard ADC with a multiplexed input can sample all LED channels, IC bare chip temperature, and LED current detection. The ADC also samples dedicated ADC inputs for system temperature compensation, LED indexing, and coding.

The TPS92664-Q1 contains registers for programming the phase shift and pulse width of each LED in the lamp string, as well as for reporting LED open and short circuit failures and functional parameters.


General specification

Type: Linear

Topology: -

Internal switch: Yes

Output number: 16

Voltage - Power supply: 4.5V ~ 60V

Voltage - output: 0V ~ 62V

Current - Output/Channel: -

Frequency: -

Dimming: PWM

Applications: Automotive, lighting

Operating temperature: -40°C ~ 125°C (TA)

Mounting type: surface mount type

Package/case: 48-TQFP bare pad

Supplier Device Package: 48-HTQFP (7x7)


Application

Automotive headlight system

ADB or non-glare high beam

Sequential turn signal, animated daytime running light

Associated Products

Model

Brand

Package

Quantity

Describe

TPS92642QPWPRQ1

TI

HTSSOP-16

3000

Synchronous step-down infrared LED driver for automobiles

TPS92543QPKDRQ1

TI

HTQFP-48

3000

Automotive-grade LED driver with 65V synchronous boost controller

NCV78343DQ0R2G

ON

SSOP-36

3000

LED driver IC, a serial pixel controller for automotive (front) lighting

NCV78514PA0R2G

ON

TSSOP-16

3000

60V, 1.5A intelligent single-channel H-bridge automotive LED driver

TLD1120EL

INFINEON

PG-SSOP-14

5500

360mA, LITIX™ - Automotive LED Driver, PG-SSOP-14

LT3763EFE

ADI

TSSOP-28

3000

60V high current step-down LED driver controller

LT3795EFE

ADI

TSSOP-28

3000

110V LED controller with spread spectrum frequency modulation function

LT3744EUHE

ADI

QFN-36

3000

High-current, synchronous step-down LED driver

LT3743EUFD

ADI

QFN-28

3000

High-current, synchronous step-down LED driver with three-state control function

LT8391EUFD

ADI

QFN-28

3000

60V, synchronous, four-switch, step-down - step-up LED controller
