Trade Name:RF Mixer
Brand:ADI
Particular Year:25+
Package:QFN-32
Delivery Date:New and Original
Stock: 3000pcs
HMC1113LP5E: RF Mixer - 10 GHz to 16 GHz, GaAs MMIC I/Q Downconverter
Model: HMC1113LP5E
Package: QFN-32
Type: RF Mixer
HMC1113LP5E - это компактный GaAs MMIC I/Q downconverter в бессвинцовом корпусе 5 x 5 мм из литого под давлением пластика для поверхностного монтажа с низкой нагрузкой. Прибор обеспечивает коэффициент усиления преобразования малого сигнала 12 дБ, коэффициент шума 1,8 дБ и характеристики зеркального отклонения 25 дБс.
В HMC1113LP5E используется МШУ, за которым следует смеситель с зеркальным подавлением, управляемый буферным усилителем LO. Этот смеситель для подавления зеркального отражения устраняет необходимость в фильтре после МШУ и удаляет тепловой шум на частоте зеркала. Он имеет выход I/Q смесителя и требует внешнего гибридного устройства с углом 90° для выбора нужной боковой полосы.
HMC1113LP5E представляет собой малогабаритную замену гибридного смесителя понижающего преобразователя с подавлением зеркала в сборе, что устраняет необходимость в проводном соединении и позволяет использовать технологии поверхностного монтажа.
Характеристики HMC1113LP5E:
Коэффициент преобразования: 12 дБ
Зеркальное отражение: 25 дБк
Изоляция LO от RF: 45 дБ
Коэффициент шума: 1,8 дБ
IP3: 1 дБм
32-контактный SMT-корпус 5 x 5 мм
Применение HMC1113LP5E:
Радиостанции «точка-точка» и «точка-многоточка»
Спутниковая связь
Мобильная радиосвязь.
