Commodity Model:HMC624ALP4E

Trade Name:Attenuator

Brand:ADI

Particular Year:25+

Package:LFCSP-24

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
HMC624ALP4E
Package
LFCSP-24
Describe
0.1 GHz to 6.0 GHz, 0.5 dB LSB, 6-bit, GaAs digital attenuator

Product Description

The HMC624ALP4E is a 6-bit digital attenuator that provides 31.5 dB of attenuation control range in 0.5 dB steps.


The HMC624ALP4E offers excellent attenuation accuracy and high input linearity over the specified frequency range of 100 MHz to 6.0 GHz. However, this digital attenuator features an external AC ground capacitor that extends the operating frequency to below 100 MHz.


The HMC624ALP4E integrates two die: a CMOS driver and a gallium arsenide (GaAs) RF attenuator. The CMOS driver supports both serial and parallel control of the RF attenuator. The device also provides user-selectable power-on states and a serial output port for cascading other serial-controlled components.


The HMC624ALP4E is powered by a single positive supply voltage ranging from 3 V to 5 V and provides a CMOS/TTL-compatible control interface.


The HMC624ALP4E is housed in a compact 4 mm × 4 mm LFCSP package compliant with RoHS standards and is pin-compatible with the HMC1122 (except for the ACGx pin).


HMC624ALP4E Features

Attenuation range: 0.5 dB (LSB) steps up to 31.5 dB

Low insertion loss: 1.6 dB at 3 GHz

Excellent attenuation accuracy

High linearity

Input 0.1 dB compression point (P0.1 dB): typical value of 33 dBm

Input third-order intermodulation point (IP3): typical value of 55 dBm

High RF input power handling capability: 28 dBm

Low phase offset: 25° at 3 GHz

Single-supply operation: 3 V to 5 V

CMOS/TTL-compatible control

24-pin, 4 mm × 4 mm LFCSP package

Pin-compatible with HMC1122


HMC624ALP4E Applications

Cellular infrastructure

Microwave radio and very small aperture terminal (VSAT)

Test equipment and sensors

Intermediate frequency (IF) and radio frequency (RF) design

Associated Products

Model

Brand

Package

Quantity

Describe

HMC305SLP4E

ADI

QFN-24

3000

Digital tunable high-pass and low-pass filters from 2 GHz to 18 GHz

HMC424ALH5

ADI

CLCC-12

3000

GaAs MMIC 6-bit Digital Attenuator, CLCC-12

HMC657LP2E

ADI

TDFN-6

3000

DC to 25 GHz, Fixed Passive SMT Attenuator, TDFN-6

HMC629ALP4E

ADI

VFQFN-24

3000

Wideband 4-bit GaAs IC Digital Attenuator, VFQFN-24

QAT-30

Mini-Circuits

MCLP

2000

50Ω 1W 30dB 50GHz Fixed Attenuator

QAT-4

Mini-Circuits

MCLP

2000

50Ω 1.7W 4dB 50GHz Fixed Attenuator

MAAD-011045-TR0500

MACOM

VFQFN-20

3500

DC - 18GHz, 0.5 dB LSB, 6-Bit Digital Attenuator

ADRF5474BCZ

ADI

CHIP-16

3000

10MHz to 60GHz, 2dB LSB, 4-Bit, Die on Carrier, Silicon Digital Attenuator

ADRF5473BCZ

ADI

CHIP-18

3000

100MHz to 40GHz 0.5 dB LSB, 6-Bit, Die on Carrier, Silicon Digital Attenuator

HMC539ALP3E

ADI

QFN-16

7764

0.25 dB LSB GaAs MMIC 5-bit Digital Positive Control Attenuator, DC - 4 GHz
