The MAX14434FAWE is the fastest and lowest power 4-channel digital galvanic isolator on the market today using Maxim's proprietary process technology. The device transfers digital signals between circuits in different power domains with a power consumption as low as 0.58 mW per channel. 0.58 mW per channel at 1 Mbps and 1.8 V supply voltage.

Features

Fast and reliable galvanic isolation of digital signals

200Mbps data rate

Withstand 5kVRMS for 60 seconds (VISO)

Withstand 848VRMS continuously (VIOWM)

Withstand ±10kV surge between GNDA and GNDB with a waveform of 1.2/50μS

High CMTI (50kV/μs, typical)

Low power consumption

1.1mW per channel at 1Mbps, VDD=3.3V

3.5mW per channel at 100Mbps, VDD=1.8V

Multiple options to support various applications

2 data rates (25Mbps, 200Mbps)

3-channel directional configuration

2 output default states (high/low)

Applications

Industrial automation fieldbus communications

Isolated RS-485/RS-422, CAN

General purpose isolated applications

Battery management

Medical systems
