The ADUM1201CRZ is a high-performance dual-channel digital isolator based on Analog Devices' iCoupler® technology. This chip integrates high-speed CMOS with monolithic transformer technology to provide two independent isolated channels, supporting various channel configurations and data rates. It features low pulse width distortion (less than 3 ns) and strict channel-to-channel matching characteristics, and ensures DC correctness under no input logic transition and power-on/power-off conditions.

ADUM1201CRZ Technical Specifications

Number of channels: 2

Channel directionality: 1/1

Maximum data rate: 25 Mbps

Isolation voltage: 2500 Vrms

Common-mode transient immunity (CMTI): 35 kV/µs

Operating temperature range: -40°C to +105°C

Supply voltage range: 2.7V to 5.5V

Rise/fall time: 2.5 ns

Propagation delay: 45 ns

Package type: SOIC-8

Mounting method: Surface mount

ADUM1201CRZ Features

8-pin narrow-body SOIC package, RoHS compliant

Low power consumption

Bidirectional communication

3 V/5 V level conversion

Maximum operating temperature: 125 °C

High data rate: dc to 25 Mbps (NRZ)

Precision timing characteristics

High common-mode transient immunity: >25 kV/μs

Automotive version certified to AEC-Q100

ADUM1201CRZ Applications

Space-critical multi-channel isolation

SPI interface/data converter isolation

RS-232/RS-422/RS-485 transceiver isolation

Digital fieldbus isolation

Hybrid vehicles, battery monitors, and motor drives
