The ADUM1200CRZ is a dual-channel digital isolator with 2/0 channel directionality, based on ADI's iCoupler® technology. This isolator integrates high-speed CMOS with single-chip transformer technology, offering superior performance characteristics compared to alternative devices such as optocouplers.

ADUM1200CRZ Features

8-pin narrow-body SOIC package, RoHS compliant

Low-power operation

Bidirectional communication

3 V/5 V level conversion

Maximum operating temperature: 125 °C

High data rate: dc to 25 Mbps (NRZ)

Automotive version certified to AEC-Q100

Technical Specifications

Brand: ADI (Analog Devices)

Model: ADUM1200CRZ

Package: 8-SOIC (3.9 mm wide)

Isolation technology: iCoupler® magnetic coupling

Number of channels: 2 (unidirectional)

Isolation voltage: 2.5 kV RMS

Data rate: 25 Mbps

Propagation delay: 45 ns (maximum)

Supply Voltage: 2.7V–5.5V

Operating Temperature: -40°C to +105°C

ADUM1200CRZ Applications

Multi-channel isolation where size is critical

SPI interface/data converter isolation

RS-232/RS-422/RS-485 transceiver isolation

Digital fieldbus isolation

Hybrid vehicles, battery monitors, and motor drives
