The LT3980EDE is a single-chip, step-down switching regulator with adjustable frequency (100kHz to 2.4MHz), capable of accepting input voltages up to 58V (with transient voltages up to 80V). The LT3980EDE chip is equipped with a high-efficiency 200mΩ switch, a boost Schottky diode, as well as the necessary oscillator, controller and logic circuits. This device has the following core characteristics:

Wide input voltage range: 3.6V to 58V during operation

The overvoltage locking function can protect the circuit from safely withstanding a transient voltage of 80V

Maximum output current of 2A

Low ripple (<15 MVP-P) Burst Mode® operation:

IQ = 85μA (from 12VIN to 3.3VOUT)

Adjustable switch frequency: 100kHz to 2.4MHz

Low shutdown current: IQ < 1μA

Clamping diode current detection can protect the circuit from damage caused by short circuits and input overvoltage conditions

Synchronous frequency range: 250 KHZ to 2MHz

Good marking of power supply

Saturated switch design: 200mΩ on-resistance

Thermal protection

Soft starting capability

Small-sized 16-pin heat-resistant performance enhanced MSOP and 3mm x 4mm DFN package

In addition, the LT3980EDE can further enhance the efficiency level under low output current conditions by absorbing the bias current from the output when the VOUT is higher than 3V.

Typical applications

Automobile battery regulation

Distributed power source regulation

Industrial power supply

Transformer regulation on the wall
