EP5368QI is a synchronous buck converter with integrated Inductor, PWM controller, MOSFETS, and Compensation providing the smallest possible solution size. The EP5368QI requires only two small MLCC capacitors to make a complete solution. EP5368QI operates at a switching frequency of 4MHz, enabling this unprecedented level of integration and small external components.

Specification Of EP5368QI

Series:Enpirion® 5300

Type:Non-Isolated PoL Module

Number of Outputs:1

Voltage - Input (Min):2.4V

Voltage - Input (Max):5.5V

Voltage - Output 1:0.603 ~ 5.1V

Current - Output (Max):600mA

Applications:ITE (Commercial)

Features:Remote On/Off, OCP, OTP, SCP, UVLO

Operating Temperature:-40°C ~ 85°C

Efficiency:94%

Control Features:Enable, Active High

Features Of EP5368QI

Integrated Inductor

3mm x 3mm x 1.1mm QFN package

Only two low cost MLCC caps required

4 MHz switching frequency

High efficiency, up to 94%

Up to 700mA continuous output current

Wide 2.4V to 5.5V input range

VOUT Range 0.603V to VIN – 0.4V

100% duty cycle capable

Less than 1 µA standby current

Low VOUT ripple for RF compatibility

Short circuit and over current protection

UVLO and thermal protection

Stable over entire operating range

RoHS compliant; MSL 3 260°C reflow

Applications Of EP5368QI

Noise sensitive RF applications

Area constrained applications

Smart phones and PDAs

Personal Media Players

Advanced Mobile Processors, DSP, IO, Memory, Video, Multimedia Engines
