SI8642BD-ASR is a high-performance digital isolator designed for applications requiring high isolation voltage and high-speed data transmission. This chip provides 4-channel isolation supporting data transfer rates up to 150Mbps, making it suitable for diverse industrial and communication systems.

SI8642BD-ASR Product Features

High isolation voltage: Provides 5000Vrms isolation voltage, ensuring safety and reliability in high-voltage environments.

High-Speed Data Transfer: Supports data transfer rates up to 150Mbps to meet high-speed communication demands.

Low-Power Design: Suitable for battery-powered devices, reducing energy consumption.

Wide Operating Temperature Range: -40°C to 125°C, accommodating diverse harsh environments.

Multi-protocol compatibility: Compatible with I²C and SMBus protocols, facilitating integration with diverse microcontroller systems.

High common-mode transient immunity: Minimum common-mode transient immunity (CMTI) of 35kV/µs effectively suppresses noise.

SI8642BD-ASR Specifications

Isolation voltage: 5000Vrms

Data transfer rate: Up to 150Mbps

Propagation delay: Maximum 13ns (rise time/fall time)

Operating temperature range: -40°C to 125°C

Package type: 16-pin SOIC package.

Number of Channels: 4 channels

Operating Voltage Range: 2.375V to 5.5V

Maximum Operating Isolation Voltage: 1200Vp

Maximum Output Current Drive Capability: 10mA

Maximum Power Dissipation: 275mW

The SI8642BD-ASR finds extensive application in the following domains:

Industrial Automation: Ensures reliable and secure data communication in motor control systems, PLCs, and similar equipment.

Renewable Energy Systems: Achieves high-voltage isolation and data transmission in equipment such as solar inverters.

Electric Vehicle Charging: Provides isolation protection for electric vehicle charging equipment.

Medical Devices: Ensures patient and equipment safety in medical monitoring and diagnostic equipment.

Telecommunications Systems: Enables high-speed data communication in base stations and network equipment.
