MAX6816EUS is single switch debouncers that provide clean interfacing of mechanical switches to digital systems. They accept one or more bouncing inputs from a mechanical switch and produce a clean digital output after a short, preset qualification delay. Both the switch opening bounce and the switch closing bounce are removed. Robust switch inputs handle ±25V levels and are ±15kV ESD-protected for use in harsh industrial environments. They feature single-supply operation from +2.7V to +5.5V. Undervoltage lockout circuitry ensures the output is in the correct state upon power-up.

Specification Of MAX6816EUS

Threshold Voltage:2.4 V

Number of Inputs Monitored:1 Input

Output Type:Active High, Push-Pull

Supply Voltage - Max:5.5 V

Minimum Operating Temperature:- 40 C

Maximum Operating Temperature:+ 125 C

Operating Supply Current:6 uA

Overvoltage Threshold:2.6 V

Pd - Power Dissipation:320 mW

Power Fail Detection:Yes

Supply Voltage - Min:2.7 V

Undervoltage Threshold:1.9 V

Unit Weight:92 mg

Features Of MAX6816EUS

Switch Debouncer Integration Simplifies System Interface to Mechanical Switches

Single-Supply Operation from +2.7V to +5.5V

No External Components Required

6µA Supply Current

Built-In Protection Circuitry Improves System Reliability

Inputs Can Exceed Power Supplies up to ±25V

ESD Protection for Input Pins

±15kV—Human Body Model

±8kV—IEC 1000-4-2, Contact Discharge

±15kV—IEC 1000-4-2, Air-Gap Discharge

Applications Of MAX6816EUS

µP Switch Interfacing

Industrial Instruments

Membrane Keypads

PC-Based Instruments

Portable Instrumentation
