The MAX6749KA is a low-power, microprocessor (µP) monitoring circuit designed to monitor single- or dual-supply system voltages ranging from 1.575V to 5V, providing stable reset output and watchdog functionality. These devices trigger a reset when the VCC supply voltage or RESET IN drops below the reset threshold or when the manual reset is pulled low. After VCC and RESET IN rise above the reset threshold, the reset signal remains active for one reset timeout cycle. The reset function is not affected by power supply transients.

The MAX6749KA features a factory-preset reset threshold with ±2% accuracy, ranging from 1.575V to 5.0V in 100mV increments.

The reset and watchdog delays can be adjusted via external capacitors. The MAX6749KA includes a watchdog select input pin that can extend the watchdog timeout period by up to 128 times.

The MAX6749KA offers push-pull or open-drain/RESET output. The MAX6749KA is available in an 8-pin SOT23 package and operates within the automotive temperature range (-40°C to +125°C).

Product Features — MAX6749KA

Factory-preset reset threshold, range 1.575V to 5V, in 100mV steps

Adjustable reset threshold options

Single/dual voltage monitoring

Capacitor-adjustable reset timeout period

Capacitor-adjustable watchdog timeout period

Minimum/maximum (with window) watchdog options

Manual reset input option

Guaranteed normal output of /RESET when VCC ≥ 1V

3.7µA supply current

Push-pull or open-drain/RESET output options

Immune to power supply transients

Small size, 8-pin SOT23 package

Product parameters — MAX6749KA

Type: Simple reset/power-on reset

Number of monitored voltages: 1

Voltage - threshold: Adjustable/selectable

Output: Open-drain or open-collector

Reset: Low active

Reset timeout: Minimum 5.692ms

Operating temperature: -40°C to 125°C (TA)

Mounting type: Surface mount

Applications — MAX6749KA

Automotive

Battery-powered computers/controllers

Computers

Precise µP monitoring

Embedded controllers

Smart meters

Medical devices

Portable devices

Set-top boxes
