The MAX6369KA is a single-channel, ultra-low-power watchdog monitor in an 8-pin SOT23 package. By selecting three logic pins, users can choose from eight watchdog timeout periods (1 ms – 60 s) and eight start-up delays (1 ms – 60 s) on-site, without the need to power down the system. This allows microprocessor systems to automatically reset or trigger an alarm in the event of an anomaly.

MAX6369KA Product Attributes

Product Type: Monitoring Circuit

Type: Voltage Supervisory

Mounting Style: SMD/SMT

Package/Case: SOT-23-8

Threshold Voltage: Adjustable

Number of Monitored Inputs: 1 Input

Output Type: Open Drain

Manual Reset:    No Manual Reset

Watchdog Timer:    Watchdog

Battery Backup Switch:    No Backup

Maximum Supply Voltage:    5.5 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Series:    MAX6369

Chip Enable Signal:    No Chip Enable

Height:    1.1 mm

Length:    2.9 mm

Operating Power Supply Current:    10 uA

Pd-Power Dissipation:    700 mW

Power Failure Detection:    No

MAX6369KA Applications

Automotive

Precise µC and Microcontroller (µC) Monitoring

Embedded Control Systems

Industrial Controllers

Networking

Telecommunications
