The IKWH50N65WR6XKSA1 650V discrete IGBT is packaged in TO-247-3-HCC, enabling a rich product portfolio with a rated current of 50A, easily replacing the previous generation technology. Such as Infineon TRENCHSTOP 5 WR5, HighSpeed 3 H3 technology. The device is optimized for power factor correction (PFC) for home and commercial air conditioning systems as well as welding applications.

Product Specifications:

IGBT type: trench type field cut-off

Voltage-emitter breakdown (Max) : 650 V

Current - Collector (Ic) (Max) : 85 A

Current-collector pulse (Icm) : 150 A

Vce(on) (Max.) for different Vge and Ic: 1.85V@15V, 50A

Power - Max. : 205 W

Switching power: 1.5mJ (on), 730µJ (off)

Input type: Standard

Grid charge: 144 nC

Td (On/off) at 25°C: 40ns/351ns

Test conditions: 400V, 50A, 22 ohms, 15V

Operating temperature: -40°C ~ 175°C (TJ)

Installation type: Through hole

Package/housing: TO-247-3

Supplier device package: PG-TO247-3-32
