The IRSM836-044MA is a 4A, 250V integrated power module (IPM) specifically designed for high-efficiency home appliance motor drive applications, such as energy-saving fans and water pumps. IR's technology provides an extremely compact, high-performance AC motor driver in an isolated package. This advanced IPM combines IR's low RDS(on) trench MOSFET technology with industry-leading 3-phase high-voltage, durable drivers, all packaged in a compact PQFN package. The surface-mount package measures just 12x12mm and includes bootstrap functionality, making its compact footprint ideal for space-constrained applications. Integrated overcurrent protection, fault reporting, and undervoltage lockout functions provide high levels of protection and safe operation. The IRSM836-044MA operates without a heat sink.

IRSM836-044MA Features

Integrated gate driver and bootstrap functionality

Open-leg current sensing

Protection shutdown pin

Low RDS(on) trench MOSFET

Undervoltage lockout function on all channels

Matching propagation delay on all channels

Optimised dV/dt to balance losses and EMI performance

3.3V Schmitt trigger high-level active input logic

Logic design to prevent cross-conduction

Motor power range up to ~150W without a heat sink

Isolation voltage over 1500VRMS

IRSM836-044MA Product Attributes

Type:    3-phase

Output current:    4 A

Operating power supply current:    3.35 mA

Minimum operating temperature:    -40°C

Maximum operating temperature:    +150°C

Mounting Style:    SMD/SMT

Package/Case:    PQFN-36

Supply Voltage - Maximum:    18.5 V

Supply Voltage - Minimum:    11.5 V
