The FS450R12KE3 is a high-performance six-unit IGBT module belonging to the EconoPACK™ + B series. This product is suitable for high-power applications such as industrial motor drives, variable frequency drives, UPS power supplies, and photovoltaic inverters. The module employs Trench Field Stop (TFS) IGBT technology, featuring low conduction losses, high switching frequencies, and integrated temperature monitoring, significantly enhancing system efficiency and reliability.

Function Overview (FS450R12KE3)

Easy separation of DC and AC

Optimised thermal resistance design for efficient heat conduction between the housing and heat sink

Highest power density, suitable for compact inverter designs

Advantages (FS450R12KE3)

Compact module

Simple and reliable assembly process

No connectors or cables required

Suitable for low-inductance system designs

Product Attributes (FS450R12KE3)

IGBT Type: Trench Field-Effect

Configuration: Three-Phase Inverter

Voltage - Collector-Emitter Breakdown (Maximum): 1200 V

Current - Collector (Ic) (Maximum): 600 A

Power - Maximum: 2100 W

Vce(on) (Maximum) at Different Vge and Ic: 2.15 V @ 15 V, 450 A

Current - Collector Cutoff (Maximum): 5 mA

Input Capacitance (Cies) at Different Vce: 32 nF @ 25 V

Input: Standard

NTC Thermistor: Yes

Operating Temperature: -40°C to 125°C (TJ)

Mounting Type: Base Mount

Package/Housing: Module

Potential Applications (FS450R12KE3)

Motor Control and Drive Systems

Solar System Solutions

Commercial, Architectural, and Agricultural Vehicles (CAV)

Uninterruptible Power Supply (UPS)
