This STGIPS10K60T intelligent power module provides a compact, high performance AC motor drive in a simple, rugged design. Combining ST proprietary control ICs with the most advanced short-circuitrugged IGBT system technology, this device is ideal for 3-phase inverters in applications such as home appliances and air conditioners. SLLIMM™ is a trademark of STMicroelectronics.

STGIPS10K60T Features

• IPM 10 A, 600 V 3-phase IGBT inverter bridge including control ICs for gate driving and freewheeling diodes

• Short-circuit rugged IGBTs

• VCE(sat) negative temperature coefficient

• 3.3 V, 5 V, 15 V CMOS/TTL inputs comparators with hysteresis and pull-down / pull-up resistors

• Undervoltage lockout

• Internal bootstrap diode

• Interlocking function

• Shut down function

• DBC substrate leading to low thermal resistance

• Isolation rating of 2500 Vrms/min

• 4.7 kΩ NTC for temperature control

STGIPS10K60T Applications

• 3-phase inverters for motor drives

• Home appliances, such as washing machines, refrigerators, air conditioners and sewing machines
