The TAS6424LQDKQRQ1 device is a 4-channel digital input Class D audio amplifier designed specifically for car audio head units and external amplifier modules. Under a 14.4V power supply voltage, when the load is 4Ω and THD+N is 10%, the device can provide 27W of output power across all four channels; when the load is 2Ω and THD+N is 10%, the device can deliver 27W of output power. Compared to traditional linear amplifier solutions, D-class topology technology significantly improves device efficiency. The output switching frequency can be set above the amplitude modulation (AM) band to eliminate AM band interference and reduce output filtering requirements and costs; it can also be set below the AM band to optimise device efficiency.

The wide power supply voltage range of 4.5V to 18V helps minimise audio distortion in start-stop applications.

The TAS6424LQDKQRQ1 integrates all the features required for demanding OEM applications. The device includes built-in load diagnostic functionality to detect and diagnose misconnected outputs, as well as detect AC-coupled high-frequency speakers, helping to reduce test time during manufacturing.

The TAS6424LQDKQRQ1 is available in a 56-pin HTSSOP PowerPAD™ package with an exposed thermal pad facing upward.

Features of the TAS6424LQDKQRQ1

• Compliant with automotive application standards

• Audio input

– 4-channel I2S or 4/8-channel TDM input

– Input sampling rates: 44.1kHz, 48kHz, 96kHz

– Input formats: 16-bit to 32-bit I2S and TDM

• Audio output

– 4-channel bridge-tied load (BTL), optional parallel bridge-tied load (PBTL)

– Output switching frequency up to 2.1MHz

– Output power of 27W at 4Ω load, 14.4V supply voltage, and 10% THD

– Output power of 27W at 2Ω load, 14.4V supply voltage, and 10% THD

– Output power of 80W at 2Ω load, 18V PBTL, and 10% THD

• Audio performance at 4Ω load and 14.4V supply voltage

– Total harmonic distortion plus noise (THD+N) < 0.03% at 1W output power

– 42µVRMS output noise

– –90dB crosstalk

• Load diagnostic functions

– Output load open circuit and short circuit

– Output short circuit to battery or ground

– Line output detection up to 6kΩ

– Operates even without an input clock

– AC diagnostic function for high-frequency speaker detection

• Protection

– Output current limiting

– Output short-circuit protection

– 40V load dump

– Withstands ground open-circuit and power supply open-circuit

– DC offset

– Over-temperature

– Under-voltage and over-voltage

• Normal operation

– Evaluation module (EVM) compliant with CISPR25-L5 electromagnetic compatibility (EMC) standards

– Power supply voltage from 4.5V to 18V

– I2C control with 4 address options

– Clipping detection and thermal warning

Applications for TAS6424LQDKQRQ1

• Car audio head units

• Car external amplifier modules
