For picture reference, please see the specifications
< >

Commodity Model:MAX25608EAUI

Trade Name:Automotive LED Driver

Brand:Maxim

Particular Year:25+

Package:TSSOP-28

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Maxim
Model
MAX25608EAUI
Package
TSSOP-28
Describe
12 Switches, LED Matrix Manager, TSSOP-28

Product Description

MAX25608EAUI: 12-Switch, High-Brightness LED Matrix Manager for Automotive Headlights


Basic Information:

Model: MAX25608EAUI

Package: TSSOP-28

Type: LED Matrix Manager


Overview:

The MAX25608EAUI is a 12-switch matrix manager IC for automotive lighting applications that includes a 12-switch array for bypassing individual LEDs in single- or dual-string applications.They feature 12 independently controlled n-channel MOSFET switches rated at 14 V with an on-resistance of 0.06 Ω. A single current source can be used to power all of the LEDs in a series. Individual LEDs can be dimmed by turning the bypass switch on and off on each LED.


MAX25608EAUI - Product Attributes:

Type: Linear

Internal Switch: Yes

Number of Outputs: 12

Voltage - Supply (minimum): 4V

Voltage - Supply (Max): 60V

Current - Output/Channel: 1.6A (switched)

Frequency: 16.384MHz

Dimming: PWM

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Shell: 28-SOIC (0.173’, 4.40mm Width)


MAX25608EAUI - Applications:

Automotive Matrix LED Systems

Adaptive Drive Beam Lamps
