The HD3SS215ZXHR is a high-speed, wide common-mode range passive switch that supports DisplayPort HBR2 and High-Definition Multimedia Interface (HDMI) applications requiring a 4k2k 60Hz refresh rate. The HD3SS215ZXHR can be configured to support two source devices connected to one receiver device, or one source device connected to two receiver devices. To support these video standards, the HD3SS215ZXHR can also switch Display Data Channel (DDC) and Hot Plug Detection (HPD) signals, which are applicable for HDMI or Digital Video Interface (DVI) applications. The device can also switch Auxiliary (AUX) and Hot Plug Detection (HPD) signals for DisplayPort applications. The HD3SS215ZXHR supports a wide common-mode range and DC/AC-coupled links, offering unique flexibility and making it an ideal choice for many applications.

HD3SS215ZXHR Features

• Universal 2:1/1:2 differential switch

• Compliant with DisplayPort electrical standards

• Compliant with HDMI electrical standards

• 2:1 and 1:2 switching supports data rates up to 6 Gbps

• Supports HPD switching

• Supports AUX and DDC switching

• –3 dB differential bandwidth up to 7 GHz

• Excellent dynamic characteristics (at 3 GHz)

– Crosstalk = –35 dB

– Isolation = –21 dB

– Insertion loss = –1.6dB

– Return loss = –12dB

– Maximum bit-to-bit distortion = 5ps

• VDD operating range: 3.3V ± 10%

• Commercial temperature range: 0°C to 70°C (HD3SS215)

• Package: 5mm x 5mm, 50 solder balls

• Output Enable (OE) pin disable switch for power saving

• Power consumption:

– Operating power consumption < 9mW (typical)

– Standby power consumption < 30µW (maximum) (when OE = L)

HD3SS215ZXHR Applications

• Desktop and laptop applications:

– PCI Express Gen 1, Gen 2 switches

– DP switches

– HDMI switches

– LVDS switches

• Networked peripherals and printers

• Home theatre and entertainment

• Televisions

• Gaming

• Professional audio, video, and signage
