For picture reference, please see the specifications
< >

Commodity Model:MAX9724BETC

Trade Name:Audio Amplifier

Brand:Maxim

Particular Year:20+

Package:LFCSP-12

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Maxim
Model
MAX9724BETC
Package
LFCSP-12
Describe
60 mW, DirectDrive, stereo headphone amplifier with low RF interference sensitivity and shutdown control

Product Description

The MAX9724BETC is a low-power, high-performance stereo headphone amplifier from Maxim that uses DirectDrive® technology and is suitable for portable audio devices. The chip is a Class AB amplifier that supports single-supply operation from 2.7V to 5.5V and is suitable for consumer electronics devices such as smartphones, MP3 players, and laptops.


MAX9724BETC — Amplifier IC for Headphones, 2-Channel (Stereo) AB Class

Type: AB Class

Output Type: Headphones, 2-Channel (Stereo)

Maximum Output Power per Channel at Different Loads: 63mW x 2 @ 32 Ohms

Voltage - Supply: 2.7V to 5.5V

Features: Pop noise elimination, short-circuit protection, and thermal protection, shutdown

Mounting Type: Surface Mount

Operating Temperature: -40°C to 85°C (TA)


Features

Enhanced RF noise suppression (up to 67dB, significantly better than typical amplifiers)

No large DC blocking capacitor required

Low-power shutdown mode, < 0.1µA

-1.5V/V fixed gain (MAX9724B)

0.02% THD+N

High PSRR (80dB at 1kHz), no LDO required

Internal integration of click-pop noise suppression circuit

Operates on a single power supply of 2.7V to 5.5V

Low static current (3.5mA)


Product Applications

Cellular phones

DVD players

Handheld game consoles

MP3 players

Laptop PCs

PDAs

Smartphones

Associated Products

Model

Brand

Package

Quantity

Describe

IRS2052M

INFINEON

MLPQ-48

2500

2-channel digital audio amplifier

IRS2452AM

INFINEON

MLPQ-32

2500

Audio amplifier IC 2 channels (stereo) Class D 32MLPQ

TPA3100D2PHP

TI

HTQFP-48

2250

20W stereo, 10V to 26V supply voltage, analogue input Class D audio amplifier

TPA3128D2DAPR

TI

HTSSOP32

12000

30W stereo, 60W mono, 4.5V to 26V, analogue input Class D audio amplifier

TAS5753MDDCAR

TI

HTSSOP-48

30000

20W Stereo, 39W Mono, 4.5V to 26.4V, Digital Input Open-Loop Class-D Audio Amplifier with AGL and HP

TDF8546JV

NXP

DBS-27

4000

I2C-bus controlled 4 x 45 W best efficiency amplifier

ALC1320-CG

REALTEK

QFN

3000

SoundWire Ultrasonic Intelligent Audio Amplifier IC

TAS5825MRHBR

TI

VQFN-32

12000

38W Stereo, 65W Mono, 4.5V to 26V, Digital Input Class D Smart Audio Amplifier with 192kHz Architecture

HFA80A-F2Y

ST

LQFP-48

2000

4 Channel Analog Input Automotive Class-D Audio Power Amplifiers

MPQ7795GRE-AEC1

MPS

24-QFN

3000

2.2MHz, low EMI, 24.5W, mono BTL Class D audio amplifier with diagnostic function
