The TPA3111D1PWPR device is a 10 W, high-efficiency Class-D audio power amplifier designed to drive bridged speakers. Advanced electromagnetic interference (EMI) suppression technology enables the use of inexpensive ferrite bead filters at the output while meeting electromagnetic compatibility (EMC) requirements. The SpeakerGuard speaker protection system includes an adjustable power limiter and a DC detection circuit. The adjustable power limiter allows users to set a virtual voltage rail below the chip's supply voltage to limit the current flowing through the speaker. The DC detection circuit measures the frequency and amplitude of the PWM signal and shuts down the output stage if the input capacitor is damaged or there is a short circuit at the input.

The TPA3111D1PWPR can drive mono speakers as low as 4Ω. The TPA3111D1PWPR's high efficiency (>90%) eliminates the need for an external heat sink when playing music.

The output is fully protected against short circuits to ground, VCC, and between outputs. Short-circuit protection and thermal protection features include automatic recovery functionality.

TPA3111D1PWPR Product Features

At 12 V supply voltage, outputs 10 W at 10% THD+N with an 8Ω load

At 8 V supply voltage, 7 W output at 10% THD+N with a 4 Ω load

Class-D operation at 94% efficiency with an 8 Ω load eliminates the need for a heat sink

Wide supply voltage range supports operation from 8 V to 26 V

Filterless operation

SpeakerGuard™ speaker protection features include an adjustable power limiter and DC protection

Smooth pin layout facilitates PCB design

Robust pin-to-pin short-circuit protection and thermal protection with automatic recovery option

Excellent THD+N and no pop noise performance

Four selectable fixed gain settings

Differential input

TPA3111D1PWPR Product Applications

Televisions

Monitors and laptops

Consumer audio devices
