The MAX14841EATA is a high-performance 3.3V RS-485 half-duplex transceiver designed for high-speed data transmission and long-distance cable communication. Featuring high ESD protection and thermal shutdown functionality, this transceiver ensures reliable operation in harsh environments.

MAX14841EATA Core Features

High ESD protection: Extends device uptime.

Thermal shutdown: Automatically deactivates when junction temperature reaches 160°C, safeguarding the device.

True fail-safe receiver input: Guarantees logic high output when receiver input is shorted or open-circuited.

Low-current design: Reduces power requirements, suitable for low-power applications.

Hot-swap capability: Prevents erroneous transitions during power-up or hot insertion.

MAX14841EATA Specifications

Data rate: Up to 40Mbps

Operating voltage: 3V to 3.6V

ESD protection:

±35kV JEDEC JS-001-2012 Human Body Model (HBM)

±20kV IEC 61000-4-2 Air Gap Discharge

±12kV IEC 61000-4-2 Contact Discharge

Operating Temperature Range: -40°C to +125°C

Quiescent Current: Typically 1.5mA

Receiver Latency: 50mV

Package Type: 8-pin TDFN-EP (3mm x 3mm) with exposed pad

Mounting Type: Surface Mount

MAX14841EATA Typical Applications

Backplane Buses

Fieldbus Networks

HVAC Networks

Industrial Control Systems

Motion Controllers
