For picture reference, please see the specifications
< >

Commodity Model:LT6108IDCB-1

Trade Name:Current Detection Amplifier

Brand:ADI

Particular Year:22+

Package:DFN-8

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
LT6108IDCB-1
Package
DFN-8
Describe
High-end current detection amplifier with reference and comparator

Product Description

The LT6108IDCB-1 is a complete high-end current sensing device featuring a precise current sensing amplifier, an integrated voltage reference, and a comparator. The LT6108IDCB-1 includes a latch comparator, and the current sensing amplifier as well as the comparator inputs and outputs are directly accessible. The amplifier gain and comparator threshold are configured via external resistors. The open-drain comparator output enables easy connection to other system components.


The LT6108IDCB-1 has a total propagation delay of just 1.4μs (typical), enabling rapid response to overcurrent conditions. A 1MHz bandwidth allows the LT6108IDCB-1 to be used for error detection in critical applications such as motor control. The comparator's high threshold accuracy, combined with the ability to lock the comparator, ensures the LT6108IDCB-1's capability to capture high-speed events.


The LT6108IDCB-1's comprehensive technical specifications are specified over a working temperature range of -40°C to 125°C, making it suitable for industrial and automotive applications. The LT6108IDCB-1 is available in a small 8-pin DFN package.


Features (LT6108IDCB-1)

Current detection amplifier

Fast step response: 500 ns

Low offset voltage: 125 μV (maximum)

Low gain error: 0.2% (maximum)

Internal 400 mV high-precision reference

Internal comparator

Fast response time: 500 ns

Total threshold error: ±1.25% (maximum)

Locked or non-locked comparator option

Wide power supply range: 2.7V to 60V

Power supply current: 450μA

Low shutdown current: 5μA (maximum)

Specifications valid over the temperature range of -40°C to 125°C


Applications (LT6108IDCB-1)

Overcurrent and fault detection

Shunt measurement

Battery monitoring

Motor control

Automotive monitoring and control

Remote sampling

Industrial control

Associated Products

Model

Brand

Package

Quantity

Describe

AD8412ABRMZ

ADI

MSOP-8

3000

A 1.8MHz high-bandwidth current-aware amplifier with PWM suppression and 10V/V gain

MAX40204ANA

Maxim

WLP-8

2000

Current Sense Amplifier 1 Circuit Single-Ended 8-WLP (1.47x0.85)

AD8410AWBRMZ-10

ADI

MSOP-10

2000

-2 V to 70 V wide input voltage range, 2.2 MHz high bandwidth, current sense amplifier with PWM rejection and 20 V/V gain

AD8411AWBRMZ-10

ADI

MSOP-10

2000

-2V to 70V Wide Input Voltage Range, 2.7MHz High Bandwidth, Current Sense Amplifier with PWM Suppression and 50 V/V Gain

LTC2946IMS-1

ADI

MSOP-16

2000

Wide Range I2C Power, Charge and Energy Monitor

LTC2946HMS-1

ADI

MSOP-16

2000

Wide Range I2C Power, Charge and Energy Monitor

MAX4376TAUK

Maxim

SOT23-5

23000

Industry's first SOT23 high-side current-sense amplifier with buffered outputs

INA2181A1IDGSR

TI

VSSOP-10

16800

26V, dual channel, bi-directional, 350kHz current sense amplifier

LT6105IMS8

ADI

MSOP-8

5000

Precision, Extended Input Range Current Sense Amplifier

INA293B1QDBVRQ1

TI

SOT-23-5

3000

AEC-Q100 Compliant -4V to 110V, 1.3MHz Ultra-Precision Current Sense Amplifier
