The INA193AIDBVR is a precision current sensing amplifier, a voltage output shunt monitor in an SOT-23-5 package. The chip can detect the voltage drop across a shunt resistor over a wide common-mode voltage range of -16V to +80V, making it suitable for high-side and low-side current measurement, and offers selectable gains of 20V/V, 50V/V, or 100V/V. Its 500kHz bandwidth makes it suitable for high-speed current control loops, such as power management, motor drive, and battery monitoring systems.

INA193AIDBVR Core Features

Wide common-mode voltage range (-16V to +80V), suitable for high-voltage system monitoring.

Low static current (maximum 900μA), suitable for low-power applications.

High-precision measurement:

Gain error ±3% (over the full temperature range).

Input offset voltage (Vos) of only 2mV, reducing measurement errors.

High-speed response:

Bandwidth of 500kHz, supporting fast dynamic current detection.

Integrated protection features:

Supports low-side detection (Low-side Capable).

Thermal shutdown and overload protection, enhancing system reliability.

Small-size package (SOT-23-5), suitable for space-constrained designs.

INA193AIDBVR Key Parameters

Supply voltage: 2.7V to 18V

Quiescent current: 900μA (maximum)

Gain options: 20V/V, 50V/V, 100V/V

Input bias current: 16μA

Common-Mode Rejection Ratio (CMRR): 94dB (typical)

Operating Temperature: -40°C to +125°C

Package: SOT-23-5

INA193AIDBVR Product Applications

• Welding equipment

• Laptops

• Mobile phones

• Telecommunications equipment

• Automotive applications

• Power management

• Battery chargers
