ITS4142N is a smart high-side power switch launched by Infineon Technologies, featuring an SOT-223-4 (PG-SOT223-4) package, suitable for applications in industrial, automotive electronics, and power management fields.

Product Attributes (ITS4142N)

Product Type: Power Switch IC - Distribution

Type: High Side

Number of Outputs: 1 Output

Output Current: 1.4 A

Current Limit: 3 A

On-Resistance—Maximum: 200 mOhms

On-Time—Maximum: 100 us

Off-Time—Maximum: 150 us

Operating Supply Voltage: 12 V to 45 V

Minimum Operating Temperature: -30°C

Maximum Operating Temperature: +85°C

Mounting Style: SMD/SMT

Package/Case: SOT-223-4

Functional Features (ITS4142N)

Short-circuit protection

Current limit

Overload protection

Overvoltage protection (including load dump)

Undervoltage shutdown with automatic restart and hysteresis functionality

Switching inductive loads

Negative voltage clamping on inductive load output terminals

CMOS-compatible input

Thermal shutdown with restart functionality

Electrostatic Discharge (ESD) Protection

Ground Loss and Vbb Voltage Loss Protection

Ultra-Low Standby Current

Reverse Polarity Battery Protection (Requires External Resistor)

Improved Electromagnetic Compatibility (EMC)

Applications (ITS4142N)

• Suitable for various resistive, inductive, and capacitive loads

• Microcontroller (µC) compatible power switch for 12 V and 24 V DC industrial applications

• Replaces electromagnetic relays and discrete circuits
