The TPS2066CDR is a dual-channel, current-limited power distribution switch in an 8-SOIC package, designed for applications such as USB ports, laptops, digital TVs, and industrial equipment that require short-circuit protection and high-capacitance load drive. The chip integrates an N-channel MOSFET, supporting a 1A output current, and features fast overcurrent response, reverse current blocking, and thermal shutdown protection functions to effectively protect the system from abnormal operating conditions.

Features of TPS2066CDR

Dual power switch series

Rated currents of 0.5A, 1A, 1.5A, and 2A

Current limit tolerance of ±20% accuracy

Fast overcurrent response - 2µs (typical)

70mΩ (typical) high-side N-channel metal-oxide-semiconductor field-effect transistor (MOSFET)

Operating voltage range: 4.5V to 5.5V

Spike pulse fault reporting (FLTx)

Components with (TPS20xxC) and without (TPS20xxC-2) output discharge

Reverse current blocking

Built-in soft start

Compatible with existing

Operating temperature range: -40°C to 85°C

TPS2066CDR Parameters

Package: 8-SOIC (3.9mm × 4.9mm)

Operating temperature: -40°C to +125°C (junction temperature)

On-resistance: 90mΩ (typical)

Switching frequency: Supports PWM control

RoHS compliant: Yes

TPS2066CDR Application Scope

• USB ports/hubs, laptops, desktop computers,

• High-definition digital TVs

• Set-top boxes

• Short-circuit protection functionality
