Service Telephone:86-755-83294757
Trade Name:Power Switch IC - Power Distribution
Brand:INFINEON
Particular Year:22+
Package:PG-DSO-20
Delivery Date:New and Original
Stock: 50000pcs
The BTS724G is a four-channel smart high-side switch developed by Infineon, packaged in a PG-DSO-20 package, specifically designed for automotive electronics and industrial control applications. The chip integrates four independent high-side switch channels, each capable of delivering up to 7A of continuous current, and features comprehensive protection functions, making it suitable for driving resistive, inductive, and capacitive loads.
BTS724G Features
Four-channel independent control
7A continuous current output capability per channel
Low on-resistance (typical value 45mΩ) to reduce power loss
Comprehensive protection features
Overcurrent protection (OCP)
Short-circuit protection (SCP)
Over-temperature protection (OTP)
Undervoltage lockout (UVLO)
Diagnostic feedback functionality
Provides open-load detection (OLD)
Over-temperature status indication
Fault status output
Automotive-grade reliability
Compliant with AEC-Q100 standards
Operating temperature range: -40°C to +150°C
Passed ISO 7637-2 automotive transient testing
Low-power design
Extremely low standby current
Supports PWM control
BTS724G Parameters
Operating voltage range: 5.5V to 28V
Continuous output current: 7A per channel
On-resistance: 45 mΩ (typical)
Switching frequency: Up to 20kHz
Package: PG-DSO-20
Operating temperature: -40°C to +150°C
BTS724G Application Areas
Automotive Electronics: Suitable for various automotive body control and convenience functions, such as window regulators, seat adjustment, windscreen wipers, etc., enabling precise control and protection of various automotive components.
Industrial Applications: Can be used in industrial automation equipment, robot control systems, etc., providing high-reliability power switching solutions.
Consumer Electronics: Suitable for high-end audio equipment, smart home control centres, etc., providing stable power management and protection functions for devices.
