For picture reference, please see the specifications
< >

Commodity Model:HMC8038LP4CETR

Trade Name:RF Switch

Brand:ADI

Particular Year:23+

Package:LFCSP-16

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
HMC8038LP4CETR
Package
LFCSP-16
Describe
High isolation, silicon SPDT, non-reflective switch, 0.1 GHz to 6.0 GHz

Product Description

The HMC8038LP4CETR is a high-isolation, non-reflective, 0.1 GHz to 6.0 GH, single-pole double-throw (SPDT) switch chip in a leadless, surface-mount package. Ideal for cellular infrastructure applications, the switch enables 62 dB isolation up to 4.0 GHz, 0.8 dB low insertion loss up to 4.0 GHz, and 60 dBm input third-order intermodulation intercept. Boasts excellent power handling capabilities up to 6.0 GHz and delivers input power (VDD = 5 V) at 0.1 dB compression point (P0.1dB) for 35 dBm. The on-chip circuit uses a single positive supply voltage of 3.3 V to 5 V at very low DC, and a single positive voltage control of 0 V to 1.8 V/3. 3 V/5. 0 V. Setting the enable input (EN) to logic high places the switch in a fully off state, where the RFC is reflective.


The device pins of the HMC8038LP4CETR are ESD protected, including the RF interface, and can withstand 4 kV HMB and 1.25 kV CDM. The HMC8038LP4CETR provides fast switching and RF settling time performance of 150 ns and 170 ns, respectively. The device is available in a compact, RoHS-compliant 4 mm × 4 mm LFCSP package.


Characteristics-HMC8038LP4CETR

Non-reflective 50 Ω design

High isolation: 60 dB (typical)

Low insertion loss: 0.8 dB (typical)

High power handling

34 dBm (via path)

29 dBm (termination path)

High linearity

0.1 dB compression (P0.1dB): 35 dBm (typical)

Input third-order intermodulation intercept (IP3): 60 dBm (typical)

ESD rating

4 kV Mannequin (HBM), Class 3A

1.25 kV Charger Model (CDM)

Single positive power supply

3.3 V to 5 V

1.8 V compatible control


Application-HMC8038LP4CETR

Cellular/4G Infrastructure

Wireless infrastructure

Automotive telematics system

Mobile radio

Test equipment

Associated Products

Model

Brand

Package

Quantity

Describe

HMC194AMS8E

ADI

8-MSOP

3000

SPDT high isolation switch SMT, DC-3 GHz

HMC190BMS8E

ADI

8-MSOP

3000

GaAs MMIC SPDT switch SMT, DC-3 GHz

HMC8058G24

ADI

SMT-24

2000

SP8T non-reflective switch for DC to 2010 MHz

HMC1055LP2CE

ADI

LFCSP-8

3000

0.5GHz to 4.0GHz, GaAs, SPST switch

HMC244AG16

ADI

16-SMT

2500

SP4T sealed switch SMT, DC-4 GHz

ADRF5063BCCZN

ADI

LGA-20

2500

9 kHz to 13 GHz, differential SPDT switch

ADRF5010BCCZN

ADI

LGA-14

2500

Non-reflective silicon SPDT switch ranging from 100 MHz to 55 GHz

ADRF5030BCCZN

ADI

LGA-20

2500

100 MHz to 20 GHz, Non-Reflective, Silicon SPDT Switch

ADRF5031BCCZN

ADI

LGA-20

3000

Non-reflective silicon SPDT switch ranging from 9 kHz to 20 GHz

HMC1118LP3DE

ADI

LFCSP-16

3000

9kHz to 13GHz, High Isolation SPDT Non-Reflective Switch, LFCSP-16
