The ADS1212U is a high-precision 22-bit sigma-delta analog-to-digital converter (ADC) in an 18-pin SOIC package designed for applications requiring high-resolution, low-noise measurements.

Product Attributes-ADS1212U

Product category: Analog-to-digital converter-ADC

Series: ADS1212

Installation style: SMD/SMT

Package/Case: SOP-18

Resolution: 22 bits

Number of channels: 1 Channel

Interface Type : 3-Wire, I2C, SPI

Sampling ratio: 6.25 kS/s

Input Type: Differential

Structure: Sigma-Delta

Analog supply voltage: 4.75 V to 5.25 V

Digital supply voltage: 4.75 V to 5.25 V

Minimum operating temperature:-40 C

Maximum operating temperature: + 85 C

DNL-Differential Nonlinearity: +/-1 LSB

peculiarity : PGA, Internal Reference

Height: 2.3 mm

INL-Integral Nonlinearity: +/-0.0015% FSR

Length: 11.55 mm

Humidity sensitivity: Yes

Number of Converters: 1 Converter

Operating supply voltage: 4.75 V to 5.25 V

Pd-power dissipation: 8.5 mW

Application-ADS1212U

● Industrial process control

● Instrumentation

● Blood analysis

● Intelligent transmitter

● Portable instruments

● Weighing scale
